EVI 6000VA / 5400W Tower Online Single Phase UPS

The EVI 6000VA / 5400W Tower Online Single Phase UPS (EP-UPS6000Y11OT) is a high-performance uninterruptible power supply designed to deliver continuous, clean, and stable power to mission-critical equipment. Featuring Online Double Conversion Technology, advanced DSP control, and N+X Parallel Redundancy, this UPS ensures maximum uptime and protection for servers, networking equipment, data centers, telecommunications systems, industrial automation, and other sensitive electronic devices.

With a powerful 6000VA / 5400W capacity and a high 0.9 power factor, the EVI UPS efficiently supports demanding loads while maintaining excellent power quality and energy efficiency.

Advanced Online Double Conversion Technology

The EVI 6000VA UPS utilizes true online double conversion technology, continuously converting incoming AC power to DC and back to AC. This process completely isolates connected equipment from power disturbances such as:

• Power surges
• Voltage sags
• Brownouts
• Frequency fluctuations
• Electrical noise
• Harmonic distortions

The result is a clean and stable power output that safeguards critical systems from unexpected downtime and equipment damage.

N+X Parallel Redundancy for Maximum Reliability

One of the standout features of the EP-UPS6000Y11OT is its N+X parallel redundancy support. Multiple UPS units can operate together to:

• Increase overall power capacity
• Enhance system availability
• Eliminate single points of failure
• Provide redundancy for mission-critical environments

This makes it an ideal solution for growing businesses, server rooms, and enterprise infrastructure requiring uninterrupted power protection.

High Output Power Factor (0.9 PF)

The UPS delivers an impressive 5400W output power from its 6000VA rating thanks to its 0.9 power factor.

Benefits include:

• Supports more IT equipment
• Greater efficiency
• Better utilization of UPS capacity
• Reduced infrastructure costs

This high power factor enables organizations to maximize performance while minimizing operational expenses.

Wide Input Voltage and Frequency Range

The EVI Online UPS is engineered to handle unstable utility power conditions.

Input Voltage Range:

• 120 – 276 Vac

Input Frequency Range:

• 50Hz: 45 – 55Hz
• 60Hz: 54 – 66Hz

This wide operating range reduces battery usage during voltage fluctuations, helping extend battery life and improve system reliability.

Generator Compatible Operation

The EP-UPS6000Y11OT is fully compatible with generator power sources, making it ideal for locations where backup generators are essential.

Advantages:

• Stable operation during utility outages
• Smooth generator integration
• Reliable power continuity
• Suitable for remote facilities and industrial sites

Intelligent DSP Control System

The advanced Digital Signal Processor (DSP) provides:

• Faster response times
• Improved system stability
• Accurate monitoring
• Enhanced reliability
• Intelligent battery management

This sophisticated control technology ensures optimal UPS performance under varying load conditions.

Eco Mode for Improved Energy Efficiency

The built-in Eco Mode helps reduce power consumption while maintaining reliable protection.

Eco Mode Benefits:

• Lower operating costs
• Reduced heat generation
• Improved energy efficiency
• Environmentally friendly operation

Organizations can achieve significant energy savings without sacrificing power protection.

User-Friendly Rotating LCD Display

The modern rotating LCD display provides real-time monitoring of critical UPS parameters including:

• Input voltage
• Output voltage
• Battery status
• Load level
• Operating mode
• Alarm notifications

The adjustable display orientation ensures easy viewing in different installation environments.

Advanced Communication and Monitoring

Comprehensive communication options simplify UPS management and remote monitoring.

Standard Interfaces:

• RS232 Port
• USB Port

Optional Expansion Cards:

• SNMP Card
• Parallel Card
• Relay Card

These communication features enable integration with network management systems for proactive monitoring and maintenance.

Cold Start Capability

The UPS supports Cold Start, allowing users to power connected equipment directly from battery power even when utility power is unavailable.

This feature is particularly useful during:

• Complete power outages
• Remote deployments
• Emergency startup situations

Self-Testing and Battery Protection

For enhanced reliability, the UPS performs automatic self-diagnostics during startup.

Key Benefits:

• Early fault detection
• Improved reliability
• Reduced maintenance costs
• Extended battery lifespan
• Increased operational confidence

Terminal Port Connectivity

The UPS features professional-grade terminal connections for both input and output power.

Benefits:

• Secure electrical connections
• Enhanced reliability
• Suitable for high-power installations
• Improved safety standards

Ideal Applications

The EVI 6000VA Online UPS is ideal for:

• Data Centers
• Server Rooms
• Enterprise Networks
• Security Systems
• Medical Equipment
• Financial Institutions
• Industrial Automation
• Telecommunications Equipment
• Educational Institutions
• Mission-Critical IT Infrastructure

---

Key Specifications

Model

• EVI EP-UPS6000Y11OT

Capacity

• 6000VA / 5400W

Topology

• Online Double Conversion

Control Technology

• DSP Digital Control

Input Voltage Range

• 120 – 276 Vac

Input Current Harmonic Distortion

• < 3%

Output Power Factor

• 0.9 PF

Frequency Range

• 50Hz: 45 – 55Hz
• 60Hz: 54 – 66Hz

Parallel Redundancy

• N+X Supported

Generator Compatibility

• Supported

Communication Ports

• USB
• RS232

Optional Accessories

• SNMP Card
• Parallel Card
• Relay Card

Display

• Rotating LCD Display

Startup Feature

• Cold Start

Warranty

• 2 Years UPS Warranty
• 1 Year Battery Warranty

Why Choose the EVI 6000VA Online UPS?

The EVI EP-UPS6000Y11OT combines enterprise-grade reliability, advanced online double conversion technology, high efficiency, flexible monitoring options, and scalable redundancy capabilities. Whether protecting critical servers, networking infrastructure, or industrial systems, this UPS delivers exceptional power protection, ensuring continuous operation and peace of mind in even the most demanding environments.
